Waterproof 5-in-1 LED Controller (WiFi + 2.4G) – Max Output 12A

Model: SR5-P | IP Rating: IP66 | Certification: CE, EMC, RED

The SR5-P is a high-performance waterproof LED controller designed for flexible control across single colour, RGB, RGBW, and tunable white (CCT) lighting systems.

Built with advanced 2.4GHz wireless technology, this controller offers stable signal transmission, anti-interference capability, and seamless connectivity for both commercial and residential lighting applications.

Key Features:

• Waterproof Design (IP66):
  - Durable and suitable for both indoor and outdoor installations.

• 2.4GHz RF Control:
  - Fast, stable wireless communication with excellent range and reliability.

• App & Voice Compatibility:
  - Works with the TUYA Smart app (via 2.4GHz gateway) and supports Alexa, Google Assistant, Yandex Alice, Tmall Genie, Baidu, and Xiaomi.

• Dynamic Lighting Control:
  - Adjust brightness, colour temperature, and saturation with precision.
  - Choose from 16 million colours and 18 built-in dynamic modes (jumping, fading, gradual change).

• Automatic Signal Forwarding: Expands control range by relaying signals between controllers for unlimited distance coverage.

• Auto Synchronisation: Ensures consistent dynamic effects across multiple controllers.

• DND (Do Not Disturb) Function: Ideal for areas prone to power loss, preventing unintended activation and saving energy.

• DMX512 Support: Compatible with DMX512 LED transmitters for professional lighting control setups.

Overview:
Product Name: Waterproof 5 in 1 LED Strip Controller (2.4G)
Model No.: WR5-P

Electrical Specifications:
Input Voltage: DC 12–24V
Output: 6A per channel
Total Output: Max 12A

Communication Specifications:
Protocol: 2.4GHz RF
Remote Control Distance: 30m

Environmental & Safety Specifications:
IP Rating: IP66
Working Temperature: -20°C to 45°C
