Our 14mm Dot-Less LED Strip is a premium lighting solution, providing smooth, continuous illumination with no visible dots. This strip is one-third brighter than our 10mm option, making it ideal for architectural and retail applications that require extra brightness. Here are the key features:

Product Highlights:

  • Enhanced Brightness: One-third brighter than the 10mm dot-less LED strip, delivering superior illumination.
  • Seamless Illumination: Enjoy smooth, dot-less lighting for a sleek and professional look.
  • Easy Installation: Features 3M tape on the back for quick and simple installation.
  • Weather Resistant: IP65 rated, ensuring durability in various weather conditions.
  • Power Requirements: Operates on 24v DC for efficient and consistent performance.
  • Long-Lasting LEDs: With an estimated lifespan of 30,000 hours, you can enjoy reliable, long-term illumination.
  • Flexible Design: Capable of vertical bending to suit various installation needs.
  • Customisable Cutting: Cutting intervals of 25cm make it perfect for custom projects.
  • Max Run Length: Supports up to 5m with a single feed (power from one side).
  • LED Driver Specifications:

(These numbers account for 20% spare capacity and do not include voltage drop considerations.)



Installation Instructions:

  1. Extension Cable: Order the appropriate length of extension cable to connect between the led strip and the LED driver.
  2. Connecting to LED Driver: Attach the extended cable to the LED driver using WAGO connectors (included with pre-soldered ends). The wires are clearly marked for safe and easy connection, suitable for extra low voltage.
  3. Mounting: Secure the led strip using mounting clips, routed channels, or silicone glue.
  4. Powering Up: Plug the LED driver into a wall outlet to light up your led strip.

Please note, Flexible Neon is not responsible for any issues arising from the installation process. This guide reflects our recommended installation method for the Dot Less LED Strip.





Product Description:

Introducing our Dot Less 14mm LED Strip (5mtr) in 3000K: a premium lighting solution that offers an impressive dotless illumination. This LED strip is one-third brighter than the 10mm version, providing enhanced brightness and visibility. It is perfect for applications where the light source is visible, as its dotless technology ensures a smooth and uniform light output without any visible dots or hotspots. With its warm white colour temperature of 3000K, it creates a cosy and inviting lighting environment. The 5-meter length provides ample coverage for your lighting project. Upgrade your space with our Dot Less 14mm LED Strip (5mtr) in 3000K and enjoy its remarkable brightness, dotless technology, and premium quality that enhances any environment.



Specs

Dimensions

14mm x 4.5mm

Material

Silicone

Warranty

 2 years

Lifetime (approx)

30,000 Hours

Max Run Lengths



Single Feed

5m

Lumens approx. (LM/M)

1271 lm (LM80 Compliant)

Electrical



Voltage

24V DC

Power Consumption (W/M)

15W/M

Constant Voltage/Constant Current

Constant Voltage

Physical



Dimmable

Yes

Cutting Intervals (mm)

25mm

Bending

Vertical

Safety



IP Rating

IP65

Standard Deviation Colour Matching

 < 5

CRI

 > 90

Certifications LM80 Compliant

Features

Slim size, no light spot, Injection moulding plug, Frosted, dust-proof process, anti-UV

The above data are typical values. Due to tolerances in the production process, characteristics of electronic components, and other factors, the test parameters will have an error of ±10%.
