Product Description:
The ELG-75-24v MEAN WELL LED Driver is a high-quality power supply designed to provide reliable and efficient performance for LED lighting systems. With a 75W output power rating and 24V DC output voltage, this driver is capable of powering a wide range of LED lighting applications.
Featuring a built-in active PFC function, this LED driver can effectively correct input power factor to minimise harmonic distortion and reduce energy waste. The unit also boasts a high efficiency rating of up to 91%, which can help reduce operating costs and minimise environmental impact.
The ELG-75-24v is designed with a rugged, aluminium housing and fully potted construction, making it suitable for use in harsh and demanding environments. It also includes various protection features such as over-voltage, over-current, and short circuit protection to ensure safe and reliable operation.
This LED driver is also easy to install and features a compact design that can be easily integrated into a wide range of LED lighting applications. With its superior performance and reliability, the ELG-75-24v MEAN WELL LED Driver is an ideal choice for powering your LED lighting system.
Specs
| Input Type |
1.8M Flex & Plug
|
|---|---|
| Input Voltage |
100 ~ 305VAC
|
| Input Current |
0.45A / 230VAC, 0.38A/277VAC
|
| Output Voltage |
24V
|
| Output Current |
3.15A
|
| Constant Current Region |
12 ~ 24V
|
| Rated Output Power |
75.6W
|
| Output Type |
Constant Voltage / Constant Current
|
| Output Connector |
300mm cable
|
| Dimming Function |
No
|
|---|---|
| Prescribed Electrical Item |
Yes
|
| SELV |
Yes
|
| Efficiency |
88.00%
|
| Operating Temperature Range | |
| Warranty |
5 Years
|
| Approvals |
CE,CB,RCM
|
| IP Rating / Environmental Protection |
IP67
|
| Dimensions |
180*63*35.5mm (L*W*H)
|
| Recommended for New Designs |
Yes
|
