8x16 Flex Neon (mtr) Lemon Yellow

Our 8x16mm Flexible Neon LED Strip is a premium product designed for durability and versatility, perfect for neon signs, architectural strips, product lighting, and more. Here’s everything you need to know about this high-quality commercial grade lighting solution:

Product Highlights:

• Commercial Grade Quality: Built to last, ideal for a variety of applications including neon signs, architectural strips, and product lighting.
• Power Requirements: This 12v neon strip requires a 12v LED Driver, available for purchase in our store. Once connected, it can be plugged into a standard Australian outlet.
• Convenient Pre-Soldered Ends: Purchasing per meter? opt for pre-soldered ends and end caps for easy connection to the LED driver.
• Max Run Length: Single feed (power from one side) supports up to 5m. Double feed (power from both sides) extends up to 10m.
• Weather Resistant: IP67 rated, ensuring durability in various weather conditions.
• Customisable Cutting: Small cutting intervals of 1cm make it perfect for custom projects.
• Long-Lasting LEDs: With an estimated lifespan of 25,000 hours, you can enjoy long-term illumination.
• Please read Spec Sheets below
• LED Driver Specifications:
• 0m - 12m: Mean Well ELG 12V / 150W
• 12.1m - 19m: Mean Well ELG 12V / 200W
• 19.3m - 27m: Mean Well HLG 12V / 320W (These numbers account for 20% spare capacity and do not include voltage drop considerations.)
• Extension Cable Wire Needed (please know for longer runs there will be voltage drop which will dim the neon):
• Up to 1m: Cable Clear 2 Core 24AWG
• Up to 3m: Cable Clear 2 Core 22AWG
• Up to 5m: Cable Clear 2 Core 20AWG
• Up to 10m: Cable Clear 2 Core 18AWG
• Up to 15m: Black PVC 2 Core 16AWG

Installation Instructions:

1. Soldering/purchasing pre-soldered end: Solder the neon ends and use silicone glue for attaching end caps. Alternatively, opt for pre-soldered ends for a hassle-free connection.
2. Extension Cable: Order the appropriate length of extension cable to connect between the neon led strip and the LED driver.
3. Connecting to LED Driver: Attach the extended cable to the LED driver using WAGO connectors (included with pre-soldered ends). The wires are clearly marked for safe and easy connection, suitable for extra low voltage.
4. Mounting: Secure the neon strip using mounting channels/clips, routed channels, double-sided tape, or silicone glue.
5. Powering Up: Plug the LED driver into a wall outlet to light up your neon strip.

Please note, Flexible Neon is not responsible for any issues arising from the installation process. This guide reflects our recommended installation method for the Flexible Neon LED Strip.

Product Description:

Our 8x16 Flex Neon in Lemon Yellow: a versatile and captivating lighting solution meticulously crafted to elevate various applications. With its small cutting interval, it's tailor-made for creating eye-catching signage that commands attention, adding a bright burst of lemony vibrancy to any space.

Embracing the cheerful hue of Lemon Yellow, our Flex Neon stands out as a beacon of creativity, ideal for a myriad of settings. Whether it's illuminating interior spaces with linear precision, enhancing architectural elements, or infusing commercial environments with a sense of vibrancy, its adaptability knows no bounds. Renowned for its flexibility and luminosity, our Flex Neon is the top choice for designers and architects seeking dynamic and cost-effective lighting solutions.

Elevate your lighting project with our 8x16 Flex Neon and immerse yourself in the perfect blend of aesthetics and functionality. Its radiant glow and pliable nature allow for limitless creative possibilities, enabling you to transform any space into a visually stunning masterpiece. Whether you're adorning a storefront with the sunny charm of Lemon Yellow, highlighting architectural features, or imbuing a residential ambience with warmth, our 8x16 Flex Neon is the quintessential choice.

Please Note: Our Neon Flex is custom-cut to your desired length, with the quantity representing the meters you need. Kindly be aware that due to the cutting process, there may be a tolerance of ± 25mm in the length. We strive to provide the best quality, but please understand that slight variations may occur. Thank you for your understanding and for choosing our customisable Neon Flex lighting solution.

Specs

The above data are typical values. Due to tolerances in the production process, characteristics of electronic components, and other factors, the test parameters will have an error of ±10%.

For further details, please read the data sheet.
